Enterprise01
Fixed
A permanent outdoor network for industrial sites, remote locations and multi-building estates.
- Pole-mounted radios, wider choice of antennas
- 1U rack server for permanent installs
- Network design and RF simulation
Simsonic Radio HeadPrivate 5G for IoT.
On your own SIMs.
Your devices on your own spectrum, core and SIM cards. No shared bandwidth, no public internet.
Overview
Private 5G, finally made simple.
Private 5G has always meant complex projects and big upfront costs. Simsonic turns it into a simple service. A division of Hyper Network Group, we build programmable mobile core software that makes your network quick to set up, simple to deploy and ready to grow.
We work through channel partners, serving enterprises, government, professionals and consumers alike. Years of mobile delivery go into making complex networks simple to provision and run, wherever your devices need to reach.
Deploy private networks
Built to be deployed your way.
Our services run on a flexible architecture you can deploy however suits you, from a SIM or an eSIM downloaded by QR code, through to the cloud and beyond.
- RentUse it when you need it
- BuyTake the kit on
- OwnRun it as yours
No large upfront infrastructure cost. Every option is on a subscription.
Private 5G FWA
Your network, your sovereignty.
A fully private 4G/5G network on your own spectrum, with your own core and your own SIMs. No trenching, no shared bandwidth, no public internet exposure. Deployed in days and managed for you.
- 1.5 Gbps
- Max downlink (theoretical)
- n40 · n77
- Bands
- 100 MHz
- Max bandwidth
- Days
- To deploy
Scale
Starts small. Scales big.
- 1 Pop-up A single cell, set up in days
- 2–4 Pop-up Pro Radios per server: two portable, four on a 1U rack
- Chained Large sites Servers chained together under one 5G core
- 10,000 Enterprise Active devices on an enterprise core (1,000 standard)
Deployment
Fixed, pop-up or in-building.
One kit, three ways to run it. We design the network around your site, install it, train your team and keep it supported.
Enterprise
Pop-up · Pop-up Pro02
Pop-up
Portable 5G for events and temporary sites, set up in days and packed away after.
- Single cell or multi-cell
- Radio and server in rugged hardcases
- Buy the kit, or hire it with on-site staff
Enterprise03
In-building
Permanent indoor coverage for warehouses and the buildings your devices work in.
- Equipment suited to permanent indoor use
- Network designed around the building
- Rack server for data-centre environments
Where it’s used
Wherever the public network can’t keep up.
Events and broadcast
Private capacity for crowds, cameras and production teams.
Temporary sites and recovery
Coverage up in days where there is none, or where the usual network is down.
CCTV and security
Dedicated bandwidth for cameras and sensors, kept off the public internet.
Industrial sites and warehouses
Machines, scanners and vehicles connected across the whole site.
Ports and rail
Coverage across yards, depots, quaysides and lineside.
A fibre alternative
Wireless access where trenching fibre is slow, costly or not allowed.
The kit
Everything you need for a private 5G network, in a few cases.
The Simsonic private 5G kit: radio heads, portable servers, antennas, fibre and accessories, packed in rugged cases.
Radio
Simsonic Radio Head
High-performance 4TRx software-defined radio head
The hardcase pole-mounts directly alongside your chosen antenna, which minimises RF cabling losses. It runs MIMO in 2×2 or 4×4 configurations at bandwidths of up to 100 MHz.
- n40 · n77
- Bands
- 4TRx
- Transceiver channels
- 100 MHz
- Max bandwidth
- 14.5 kg
- Hardcase weight
Edge server
Simsonic Edge Server
Radio software and 5G core, in one portable case
A portable server in a connectorised, splashproof hardcase. It runs the radio (vRAN) software, the configuration and KPI tool and an optional 5G core. A 1U rack version suits permanent installations and data centres.
- Hardcase 330 × 305 × 155 mm
- Fibre fronthaul to each radio, on tactical reels with locking connectors
- Rack version: 1U, 370 mm deep, 12 kg, up to four radios
- vRAN + 5GC
- Optional 5G core
- Up to 2
- Radios per portable server
- 5.1 kg
- Portable hardcase
- 1U rack
- Permanent option
Network management
Simsonic Network Console
Configuration and live KPI dashboards
An intuitive interface for configuring the network and monitoring its performance, with an integrated real-time health and performance dashboard and historical per-device data. Comes with a user manual and quick-start guide.
- Network configuration from one interface
- Real-time health and performance dashboard
- Historical per-device performance data
- User manual and quick-start guide included
Network health · illustrative● Live
1.85 Gbps
Aggregate downlink, last 60 min
Cell 1842 Mbps
Cell 2611 Mbps
Cell 3398 Mbps
Core · 5GC214 devices
How it fits together
Four parts. One network that is only yours.
- 1
Radio head + antenna
The cell: a pole-mounted radio, generally within 2 m of its antenna.
- 2
Fibre fronthaul
Tactical fibre reels with locking connectors link each radio to the server.
- 3
Edge server
Runs the radio software and, optionally, the 5G core, on site.
- 4
Your devices
Cameras, sensors, handsets and routers, each authenticated with network-specific SIM cards.
Product tiers
Three ways to deploy, from a single pop-up cell to a bespoke network.
Entry
Pop-up
Single-cell pop-up network
- Radio head in a pole-mountable case
- Antenna with case and accessories kit
- Portable server
- Basic configuration and live KPI dashboard
- Add-ons: 5G core, SIM cards
Pro
Pop-up Pro
Multi-cell pop-up network
- Everything in Pop-up
- Full configuration options
- Full KPI dashboard, real-time and historic
- Multiple cells per server, servers chained for large networks
- Add-ons: extra radio kits, 5G core, SIM cards
Bespoke
Enterprise
Networks designed around your use case
- Portable or pole-mount
- Radios covering various bands
- Greater choice of antennas
- Network design and RF simulation
- Add-ons: 5G core, SIM cards, third-party core integration
Product finder
Find the right private 5G for you
Start with one question and we will point you to the right tier.
Does your use case need portable 5G equipment, or a permanent installation?
Pop-upEvents and temporary sites: Pop-up or Pop-up Pro→ FixedPermanent outdoor sites: Enterprise→ In-buildingPermanent indoor coverage: Enterprise→Questions
Private 5G, answered.
What area does one cell cover?
In the 3800 to 4100 MHz range with good line of sight, expect up to about 600 m for uploads from devices and just over 1 km for downloads. It varies with band, antenna, licence power and the site and we can run an RF simulation for yours.
What speeds can I expect?
With 100 MHz of bandwidth and 4×4 MIMO, the theoretical downlink maximum is 1,500 Mbps (up to 1,200 Mbps seen in good coverage). Uplink-biased, the theoretical maximum is 750 Mbps (600 Mbps seen).
How many cells and devices can it run?
Each portable server supports up to two radios and each 1U rack server up to four. Servers connect under one 5G core, which supports up to 1,000 active devices (enterprise cores up to 10,000).
Can I buy or hire it?
Both. Buy the equipment for a flat fee plus annual software maintenance or hire a network for an event, with equipment and on-site staff on a day rate.
Buy online on
SIMs for devices that leave site
Public-network SIMs for anything that moves beyond your private 5G. Need hardware or an install too? Our team handles it.
